level value will change with the up and down of .
Note: in slope trigger, runt trigger and windows trigger, there are two
trigger level labels (
and ).
12. CH1 Vertical Scale
Display the voltage value per grid of CH1 waveform vertically.
Use VERTICAL
SCALE to modify this parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
13. Analog Channel Label/Waveform
Different channels are marked with different colors and the colors of the channel
label and waveform are the same.
14. CH2 Vertical Scale
Display the voltage value per grid of CH2 waveform vertically.
Use VERTICAL
SCALE to modify this parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
15. CH3 Vertical Scale
Display the voltage value per grid of CH3 waveform vertically.
Use VERTICAL
SCALE to modify this parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
16. CH4 Vertical Scale
Display the voltage value per grid of CH4 waveform vertically.
Use VERTICAL
SCALE to modify this parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
17. Message Box
Display prompt messages.
18. Digital Channel Status Area
Display the current status of the 16 digital channels. The digital channels
currently turned on are displayed in green, the digital channel currently selected
is displayed in red and the digital channels turned off are displayed in grey.
Note: This function is only applicable to MSO1000Z-S and MSO1000Z models
oscilloscopes.
19. Source1 Waveform
Display the type of waveform currently set for Source1.
When the modulation is enabled,
will be displayed at the bottom of the
Source1 Waveform.
