Chapter 6 MATH and Measurement RIGOL
MSO1000Z/DS1000Z User’s Guide 6-33
Press Measure  Clear  Item n (n=1~5) to "Delete" or "Recover" the specified
measurement item.
 When the state of Item n (n=1~5) is "Delete", you can press Item n (n=1~5)
to delete the corresponding item. At this point, the Nth measurement result at
the bottom of the screen is grayed out. If a new measurement item is opened,
all items will move one-item left.
 When the state of Item n (n=1~5) is "Recover", you can press Item n (n=1~5)
to recover the corresponding item. At this point, the Nth measurement result
(from the left) at the bottom of the screen is illuminated automatically.
Press Measure  Clear  All Items to "Delete" or "Recover" the last five
parameters at the same time. When all measurement items are deleted, all
measurement results will be hidden. At this point, you can press All Items to
recover the last five items deleted at the same time.
Note: You can press and hold Measure to clear all the measurement items
currently turned on. At this point, you can recover the last five parameters turned on
by pressing Measure  Clear  Item n (n=1~5) or Measure  Clear  All
Items.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
