RIGOL Chapter 15 Accessibility Setting
15-6 MSO1000Z/DS1000Z User’s Guide
System-related
Sound
When the sound is enabled, you can hear the sound of the beeper when you press a
function key or a menu softkey or when the prompt message pops up.
Press Utility  Sound to select (off) or (on). The default is off.
Language
This oscilloscope supports menus in multiple languages as well as provides Chinese
and English help information, prompt messages and interface display. Press Utility
 Language and use to select the desired language; then, press down to
select the language.
System Information
Press Utility  System  System Info to view the system information of your
oscilloscope. The system information includes the manufacturer, model, serial
number as well as software version and board version.
Vertical Reference
When rotating VERTICAL SCALE to change the vertical scale of the analog
channel, you can expand and compress the signal vertically around the screen center
or signal ground level position.
Press Utility  System  VerticalRef. to select "Center" or "Ground". The
default is "Ground".
 Center: when the vertical scale is changed, the waveform will be expanded or
compressed around the screen center.
 Ground: when the vertical scale is changed, the waveform will be expanded or
compressed around the signal ground level position.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
