Rigol DS1074Z Plus User Manual

Chapter 18 Specifications RIGOL
MSO1000Z/DS1000Z User’s Guide 18-1
Chapter 18 Specifications
All the specifications are guaranteed except the parameters marked with "Typical"
and the oscilloscope needs to operate for more than 30 minutes under the specified
operation temperature.
Sample
Sample Mode
Real-time Sample
Real Time
Sample Rate
Analog channel: 1 GSa/s (single-channel), 500 Msa/s
(dual-channel), 250 MSa/s (3/4-channel)
Digital channel: 1 GSa/s (8-channel), 500 MSa/s (16-channel)
Peak Detect
Analog channel: 4 ns
Digital channel: 4 ns
Averaging
After all the channels finish N samples at the same time, N can
be 2, 4, 8, 16, 32, 64, 128, 256, 512 or 1024
High Resolution
12 bit (max)
Interpolation Sin(x)/x (optional)
Min Detect
Pulse Width
Digital channel: 10 ns
Memory Depth
Analog channel: standard 12M pts (single-channel), 6M pts
(dual-channel), 3M pts (3/4-channel); optional 24 Mpts
(single-channel), 12 Mpts (dual-channel), 6 Mpts (3/4-channel)
Digital channel: standard 12 Mpts (8-channel)/6 Mpts
(16-channel); optional 24 Mpts (8-channel)/12 Mpts
(16-channel)
Input
Number of
Channels
MSO1XX4Z/1XX4Z-S: 4 analog channels, 3 analog channels + 8
digital channels, 2 analog channels + 16 digital channels
DS1XX4Z Plus/1XX4Z-S Plus: 4 analog channels, MSO
upgradable
DS1054Z: 4 analog channels
Input Coupling
DC, AC or GND
Input
Impedance
Analog channel: (1 MΩ±1%) || (15 pF±3 pF)
Digital channel: (100 kΩ±1%) || (8 pF±3 pF)
Probe
Attenuation
Coefficient
Analog channel: 0.01X to 1000X, in 1-2-5 step
Maximum Input
Voltage (1MΩ)
Analog Channel:
CAT I 300 Vrms, CAT II 100 Vrms, Transient Overvoltage 1000
Vpk
Digital channel:
CAT I 40Vrms, Transient Overvoltage 800 Vpk
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
