RIGOL
Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
5-1
Chapter 5 : Specifications
All specifications apply to the DS1000CA Series Oscilloscopes and a probe with the
Attenuation switch set to 10X unless noted otherwise. To meet these specifications,
two conditions must first be met:
1 The instrument must have been operating continuously for thirty minutes within
the specified operating temperature.
2 Must perform the Self Cal operation, accessible through the Utility menu, if the
operating temperature changes by more than 5℃.
All specifications are guaranteed unless noted “typical”.
Specifications
Acquisition
Sampling Modes Real-Time Equivalent
Sampling Rate 2GSa/s
[1]
50GSa/s
[2]
Averages N time acquisitions, all channels simultaneously, N is
selectable from 2, 4, 8, 16, 32, 64, 128 and 256
Inputs
Input Coupling DC, AC, GND
Input Impedance 1MΩ±2%, in parallel with 15pF±3pF
50Ω±2%
[3]
Probe Attenuation Factors 1X, 5X, 10X, 50X, 100X, 500X, 1000X
Maximum Input Voltage
300V (DC＋AC Peak, 1MΩ input impedance)
5V (DC+AC Peak, 50Ω input impedance)
[3]
Time delay between channel
(typical)
500ps
