ExitSuspend: trigger when the bus exits from idle state for more than 10 ms.
Trigger Mode:
Press Sweep to open the trigger mode list and select "Auto", "Normal" or "Single".
For the details, please refer to "
Trigger Mode". The corresponding status light of
the current trigger mode turns on.
Trigger Setting:
Press Setting to set the trigger parameters (noise rejection) under this trigger type.
Note: Noise rejection is grayed out and disabled automatically when the signal
source is set to any channel of D0-D15.
Trigger Level:
Press D+ and use TRIGGER LEVEL to modify the trigger level of the D+
channel. Press D- and use TRIGGER LEVEL to modify the trigger level of the D-
channel. For the details, please refer to the introduction of "
Trigger Level".
