Chapter 14 Store and Recall RIGOL
MSO2000A/DS2000A User’s Guide 14-9
Disk Management
Press Storage Disk.Manage to turn on the disk management interface as
shown in Figure 14-1 and use to select the desired disk. The disk currently
selected is displayed in green and press down
to open the disk selected.
Execute the following operations through the disk management menu:
To Select File Type
To Create a New File or Folder
To Delete a File or Folder
To Rename a File or Folder
To Clear the Local Memory
To Select File Type
Except the file types in Storage, the oscilloscope can also display some files for
advanced applications such as mask file of the Pass/Fail test (*.pf), upgrade file
(*.gel), parameter file (*.txt), arbitrary waveform file (*.arb) and reference
waveform file (*.ref).
Note: Only MSO2000A-S and DS2000A-S support the *.arb file type.
Press Storage Disk.Manage File Type to select the desired file type. The
default is “*.*”. Under the current directory, only files of which the suffix of the file
name matches with the file type selected will be displayed in the current disk.
