RIGOL Chapter 14 Store and Recall
14-16 MSO2000A/DS2000A User’s Guide
Input Impedance 1 MΩ
Channel Invert OFF
Amplitude Scale Coarse
Channel Unit V
Acquisition Setting (Acquire)
Acquisition Mode Normal
Sampling Mode Real Time
Memory Depth Auto
Anti-Aliasing OFF
Trigger Setting (TRIGGER)
Trigger Level 0
Trigger Type Edge
Source CH1
Slope Rising Edge
Trigger Mode Auto
Trigger Coupling DC
Trigger Holdoff 100 ns
Noise Reject OFF
Display Setting (Display)
Display Type Vectors
Persistence Time Min
Waveform Intensity 50%
Screen Grid
Brightness 50%
Menu Display Infinite
Signal Source (Source)
[1]
Source 1 Switch OFF
Source 2 Switch OFF
Status Display OFF
Source 1 Setup/Source 2 Setup
Waveform Sine
Channel Switch OFF
