RIGOL Chapter 15 System Function Setting

MSO2000A/DS2000A User Guide

15-6

MAC Address

For each oscilloscope, the MAC address is unique. When attributing IP address for

the oscilloscope, the MAC address is usually used to identify the instrument.

VISA Address

Display the VISA address currently used by the oscilloscope.
