Chapter 16 Remote Control RIGOL
MSO2000A/DS2000A User Guide
Click to check whether the GPIB communication works
normally; if not, please follow the corresponding prompt messages to solve
the problem.
5. View device resource
The resources found will appear under the "RIGOL Online Resource" directory.
For example, MSO2302A (GPIB0::1::INSTR).
6. Control the instrument remotely
Right click the resource name "MSO2302A (GPIB0::1::INSTR)" and select "SCPI
Panel Control" to turn on the remote command control panel through which you
can send commands and read data.
