RIGOL Chapter 4 Sample System Setting
4-10 MSO4000/DS4000 User’s Guide
accordingly.
Note
[1]
: When two channels use the same sampler and only one of the two channels is turned on,
the system is in the interweave state; when both of the two channels are turned on, the system is
in the non-interweave state. For MSO4000/DS4000, CH1 and CH2 use the same sampler; CH3 and
CH4 use the same sampler.
