RIGOL Chapter 5 Trigger
5-22 MSO4000/DS4000 User’s Guide
trigger control area (TRIGGER) at the front panel turns on.
6. Turn the noise rejection on or off
Press Setting to enter the trigger setting submenu. In this submenu, press
Noise Reject to turn the noise rejection on or off (please refer to “Noise
Rejection”).
Note: When the trigger source is D0 to D15, the trigger coupling and noise
rejection are invalid.
