then press the knob. You can also press Cursor or Mode continuously to switch the
current cursor mode. The modes available are “Manual”, “Track”, “Auto” and “X-Y”.
When “OFF” is selected, the cursor measurement function is turned off.
Note: The X-Y cursor mode is only avalibale in “X-Y” time base mode (refer to “To
Specify the Time Base Mode”).
The 4 cursor modes are introduced in details in the following section.
 Manual Mode
 Track Mode
 Auto Mode
 X-Y Mode
