MSO4000/DS4000 User’s Guide 11-9
Chapter 11 Waveform Recording RIGOL
3. Set the start frame
Press Start Frame and turn the multi-function knob to set the start frame
of playback. The maximum range is from 1 to the number of frames recorded.
The default is 1.
Note: The actual range of the start frame is from 1 to the end frame currently
set (End Frame).
4. Set the end frame
Press End Frame and turn the multi-function knob to set the end frame of
playback. The maximum range is from 1 to the number of frames recorded. The
default is the number of frames recorded.
Note:
The actual range of the end frame is from the start frame currently set
(Start Frame) to the number of frames recorded.
Please distinguish the end frame here from the end frame in the waveform
“Record” mode.
5. Execute the playback operation
After setting the desired playback parameters, you can press the menu key or
the front panel shortcut key to start or stop the playback operation.
Note: Please set the playback parameters above before starting the playback
operation. You cannot set the playback parameters after the playback operation
starts.
1) Start the playback operation
Press Operate, turn the multi-function knob to select “ ” and press
the knob or directly press the playback/pause shortcut key (
) at the front
panel; the oscilloscope starts the playback according to the current settings.
During the playback process, the backlight of the playback/pause shortcut
key (
) is illuminated in yellow and flashes continuously. The number of
frame currently played back is displayed in the playback information at the
upper-right side of the screen and in Current Frame.
