MSO4000/DS4000 User’s Guide 11-17
Chapter 11 Waveform Recording RIGOL
under the pass/fail test analysis mode.
2) View the error frames or the specified frame of the current
waveform analysis
View the previous error frame
Pressing Previous or RUN/STOP can locate the error frame previous
to the “Current Error” frame.
View the next error frame
Pressing Next or SINGLE can locate the error frame following the
“Current Error” frame.
View the specified frame
Press Current Frame and turn the multi-function knob or the
inner knob of the navigation knob to adjust the data frame currently
displayed at a relatively smaller step or turn the outer knob of the
navigation knob to adjust the data frame currently displayed at a
relatively larger step. The adjustable range is from 1 to the number of
frame recorded. The default is 1.
Note: The larger the rotation amplitude of the outer knob of the
navigation knob is, the faster the variation of the value will be. When
you need to adjust the data frame currently displayed within a
relatively larger range, this function can help you quickly finish the
setting.
To Set the Template (Trace Mode)
In the waveform recording menu (Mode is set to “Analyze”), press Analyze to select
“Trace”. Then, set the template used in analysis based on trace through the method
below.
1. Specify the trace mode
Press Trace to select the creation method of analysis template.
Current Frame: select the current frame of data as the analysis template.
Average: select the average of the current data frame as the analysis
template.
