RIGOL Chapter 12 Display Control

12-4 MSO4000/DS4000 User’s Guide

3. Infinite

In this mode, the oscilloscope displays the waveform newly acquired without

clearing the waveforms acquired formerly. The waveforms acquired formerly will

be displayed in relatively low-brightness color and the newly acquired

waveforms will be displayed in normal brightness and color. Infinite persistence

can be used to measure noise and jitter and to capture incidental events.
