Rigol DS4000 Series

RIGOL Chapter 13 Store and Recall
13-24 MSO4000/DS4000 User’s Guide
Sample Rate 50 MSa/s
Anti-Aliasing OFF
Logic Operation
Expression AND
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 1 U
Threshold A 0 V
Threshold B 0 V
Advanced Operation
Expression OFF
Expression CH1+CH2
Invert OFF
Vertical Scale 2 V
Logic Analyzer (LA)
[1]
CH/Group D0
On/Off D7-D0: Turn Off; D15-D8: Turn Off
WaveSize M
ReOrder D0-D15
Level Type TTL
Bus BUS1
Bus Status Off
Sel CH D7-D0
Endian Normal
Reference Clock None
Slope Type Rising Edge
Display Type Data
Format Hex
JitterReject Turn On
JitterTime 5.00 ns
Protocol Decoding (Decode 1, Decode 2)
Decoding Type Parallel
BUS Status OFF
