RIGOL Chapter 1 Quick Start
1-14 MSO4000/DS4000 User’s Guide
Figure 1-10 Probe Compensation Signal (Square Waveform)
6. Use the same method to test the other channels.
WARNING
T
o avoid electric shock, please make sure that the insulated wire of the
probe is in good condition and do not touch the metallic part of the
probe when the probe is connected to a high voltage source.
The probe compensation signal can only be used for probe compensation
adjustment and cannot be used for calibration.
