MSO2000A/DS2000A Quick Guide
23
19. Notification Area
Display the system time, sound icon and USB storage device icon.
 System Time: displayed in "hh:mm (hour:minute)" format. When
printing or storing the waveform, the output file will contain this time
message. Press UtilitySystemSystem TimeSystem Timeto
set through the following format:
yyyy-mm-ddhh:mm:ss (year-month-datehour:minute:second)
 Sound Icon: when the sound is enabled, will be displayed.
PressUtilitySoundto enable or disable the sound.
 USB Storage Device Icon: when a USB storage device is detected, will
be displayed.
20. Operation MENU
Press any softkey to activate the corresponding menu. The following
symbols might be displayed in the menu:
Denote that onthe front panel can be used to select the
parameter items. The backlight of turns on when the parameter
selection is valid.
Denote that can be used to modify the parameter values. The
backlight of turns on when the parameter input is valid.
Denote that can be used to modify the parameter values and
press to input the desired paramrter values directly using the
pop-up numeric keyboard. The backlight of turns on when the
parameter input is valid.
Denote that you can use the "Navigation Knob" to quickly
adjust/locate parameters.
Denote that you can use to adjust the parameter and then press
down to select the parameter. The backlight of is constant
on.
Denote that the current menu has several options.
Denote that the current menu has a lower level menu.
Press this key to return to the previous menu.
Note:The following direction keys might appear in the grid at the lower-left
corner of the menu bar:
Denote that you can open the next page menu.
Denote that you can open the previous page menu.
