Rigol DS8000-R Series Quick Guide

RIGOL
12 DS8000-R Quick Guide
English
To Set the System Language
This oscilloscope supports menus in multiple languages. You can click on the
function navigation icon to open the function navigation. Then click on the
"Utility" icon to enter the utility setting menu. Click Language to select
the desired language.
To Connect the Probe
RIGOL provides the passive probe and the active probe (required to be
purchased by yourself if necessary) for DS8000-R series. For specific probe
models, please refer to DS8000-R Series Datasheet. For detailed technical
information of the probes, please refer to the corresponding Probe User Guide.
Connect the passive probe:
1. Connect the BNC terminal of the probe to an analog channel input
terminal of the oscilloscope on the front panel, as shown in Figure 5.
2. Connect the ground alligator clip or spring of the probe to the circuit
ground terminal, and then connect the probe tip to the circuit point to be
tested.
Figure 5 To Connect the Passive Probe
After you connect the passive probe, check the probe function and probe
compensation adjustment before making measurements. For detailed
procedures, refer to "Function Inspection" and "Probe Compensation".
"Shutdown" icon , the oscilloscope is powered off (you can also
press the Power key at the lower-left corner of the front panel to turn
off the oscilloscope).
