Rigol DSG821 User Manual

Chapter 6 Specifications RIGOL
DSG800 User's Guide 6-3
Frequency Sweep
Sweep type
Step sweep (equally or logarithmically spaced frequency steps)
List sweep (list with arbitrary frequency steps)
Sweep mode
Single, continuous
Sweep range
Full frequency range
Sweep shape
Triangle, ramp
Step change
Linear or logarithmic
Number of
sweep points
Step sweep
2 to 65535
List sweep
1 to 6001
Dwell time
20 ms to 100 s
Trigger mode
Auto, key, external, bus (USB, LAN)
Spectral Purity
DSG815
DSG830
Harmonic
CW mode, 1 MHz ≤ f
≤ 3 GHz, level ≤ +13
dBm
< -30 dBc
Non-harmonic
CW mode, level > -10 dBm, carrier offset > 10 kHz
100 kHz ≤ f ≤ 1.5 GHz
< -60 dBc, < -70
dBc (typ.)
< -60 dBc, < -70
dBc (typ.)
1.5 GHz < f ≤ 3 GHz
< -54 dBc, < -64
dBc (typ.)
SSB phase noise
CW mode, carrier offset = 20 kHz, 1 Hz measurement
bandwidth
100 kHz ≤ f ≤ 1.5 GHz
< -100 dBc/Hz, <
-105 dBc/Hz (typ.)
< -100 dBc/Hz, <
-105 dBc/Hz (typ.)
1.5 GHz < f ≤ 3 GHz
< -94 dBc/Hz, <
-99 dBc/Hz (typ.)
Residual FM
CW mode, RMS value at f = 1 GHz
0.3 kHz to 3 kHz
< 10 Hz rms, < 5 Hz rms (typ.)
0.03 kHz to 20 kHz
< 50 Hz rms, < 10 Hz rms (typ.)
