8) Segment Trigger Mode
Set the trigger mode of the I/Q data segment.
Press Seg Mode to select "Same Seg", "Next Seg", "Seamless" or
"Sequencer".
Same Segment
When the "Same Seg" trigger mode is selected, the instrument outputs
the same trigger segment. When Next Seg is modified, the output
segment will change accordingly.
Next Segment
When the "Next Seg" trigger mode is selected, the instrument will
switch to the output of the next segment when Execute Seg is
pressed. You can also output the corresponding segment of the
waveform by modifying Next Seg.
Seamless
When the "Seamless" trigger mode is selected, the instrument will
switch to the output of the next segment seamlessly when Execute
Seg is pressed. This menu is only valid when the sample rates of all the
waveform segments in the "Segment" file loaded are the same.
Sequencer
When the "Sequencer" trigger mode is selected, the instrument
outputs each waveform segment according to the "Seg List" (*.SEQ)
file or "Seg csv" (*.CSV) file loaded. At this point, Next Seg and
Execute Seg are grayed out and disabled. This menu is valid only
when the "Seg List" (*.SEQ) file or "Seg csv" (*.CSV) file is loaded.
Note: The above menus are valid only when the "Segment" (.SEG) file is
loaded.
9) Next Segment
You can press Next Seg to set the number of the next segment of the ARB.
10) Execute Segment
You can press Execute Seg to execute the trigger of the next segment.
This menu is only valid when the segment trigger mode is set to "Next Seg"
or "Seamless".
