Chapter 2 Front Panel Operations RIGOL
DSG800 User's Guide 2-3
To Select the LF Waveform
Press FREQ LF Waveform to set the waveform of the LF output signal to
"Sine" or "Square". The default is "Sine".
To Set the LF Amplitude
Press FREQ LF Level to set the amplitude of the LF signal.
Use the numeric keyboard to input the amplitude value and select the desired
unit from the pop-up unit menu.
The amplitude units available are V, mV, uV, nV and dBm.
You can press Backspace to delete the number at the left of the cursor.
You can press the left/right direction key to enter the parameter editing state
and move the cursor to the specified digit; then, rotate the knob to modify the
value.
You can also rotate the knob to modify the amplitude at the current step.
You can press Step to set the step.
The settable ranges of the amplitudes of sine and square are both from 0 V to 3
V. Note that when the frequency is 0 Hz, the LF output is DC signal and the
settable range of the amplitude is from -3 V to 3 V.
To Set the LF Frequency
Press FREQ LF Freq to set the frequency of the LF signal.
Use the numeric keyboard to input the frequency value and select the desired
unit from the pop-up unit menu.
The frequency units available are GHz, MHz, kHz and Hz.
You can press Backspace to delete the number at the left of the cursor.
You can press the left/right direction key to enter the parameter editing state
and move the cursor to the specified digit; then, rotate the knob to modify the
value.
After the frequency is set, you can rotate the knob to modify the frequency at
the current step.
You can press Step to set the step.
