Chapter 1 Quick Start RIGOL
DSG800 User Guide 1-17
User Interface
The user interface of DSG800 series RF signal generator is shown in the figure below.
1 2 3 4
5 6
Figure 1-6 User Interface
1. Frequency Area
Display the current frequency settings of the RF signal generator.
—
: continuous sweep label. It is displayed when the sweep manner is
"Freq" or "Freq & Lev" and the sweep mode is "Cont".
—
: single sweep label. It is displayed when the sweep manner is "Freq"
or "Freq & Lev" and the sweep mode is "Single".
—
: forward sweep label. It is displayed when the sweep manner is "Freq"
or "Freq & Lev" and the sweep direction is "Fwd".
—
: downward sweep label. It is displayed when the sweep manner is
"Freq" or "Freq & Lev" and the sweep direction is "Down".
—
: frequency sweep progress bar. It is displayed when the
sweep manner is "Freq" or "Freq & Lev".
2. Amplitude Area
Display the current level settings of the RF signal generator.
—
: displayed when the flatness calibration is turned "On".
—
: continuous sweep label. It is displayed when the sweep manner is
"Level" or "Freq & Lev" and the sweep mode is "Cont".
—
: single sweep label. It is displayed when the sweep manner is "Level"
or "Freq & Lev" and the sweep mode is "Single".
—
: forward sweep label. It is displayed when the sweep manner is
