Rigol DSG821 - Appearance and Dimensions

Chapter 1 Quick Start RIGOL
DSG800 User Guide 1-3
Appearance and Dimensions
236
112
Figure 1-1 Front View (unit: mm)
261.5
208
318.40
272.40
14.70
Figure 1-2 Top View (unit: mm)
