RIGOL
XII MSO7000/DS7000 User Guide
Format Conventions in this Manual:
1. Key
The key on the front panel is denoted by the format of "Key Name (Bold) + Text
Box" in the manual. For example, Utility denotes the "Utility" key.
2. Menu
The menu items are denoted by the format of "Menu Word (Bold) + Character
Shading". For example, System denotes the "System" menu item under
Utility.
3. Operation Procedures:
→ denotes the next step of operation. For example, Utility → System denotes
that first press Utility, and then press the System key.
4. Connector:
The connectors on the front or rear panel are usually denoted by the format of
"Connector Name (Bold) + Square Brackets (Bold)". For example, [TRIG OUT].
5. Knob
Label
Knob
Label
Knob
Horizontal SCALE
Horizontal Time
Base Knob
Vertical SCALE
Vertical Scale
Knob
Horizontal
POSITION
Horizontal Position
Knob
Vertical
OFFSET
Vertical
Offset Knob
Wave Vertical
SCALE
Waveform Vertical
Scale Knob
Trigger LEVEL
Trigger Level
Knob
Wave Vertical
POSITION
Waveform Vertical
Position Knob
Multifunction
Knob
Content Conventions in this Manual:
MSO7000/DS7000 series includes the following models. Unless otherwise specified,
this manual takes MSO7054 as an example to illustrate the functions and operation
methods of MSO7000/DS7000 series.
Model
Analog
Bandwidth
No. of
Analog
Channels
No. of
Channels of
Function/AWG
No. of Digital
Channels
DS7054
500 MHz
4
——
——
DS7034
350 MHz
4
——
——
DS7024
200 MHz
4
——
——
DS7014
100 MHz
4
——
——
MSO7054
500 MHz
4
2, Opt.
16
MSO7034
350 MHz
4
2, Opt.
16
MSO7024
200 MHz
4
2, Opt.
16
MSO7014
100 MHz
4
2, Opt.
16
