Chapter 11 Protocol Decoding RIGOL
MSO7000/DS7000 User Guide 11-3
Falling : samples the channel data on the falling edge of the clock.
Both : samples the channel data on both the rising edge and the
falling edge of the clock.
âš« Set the threshold
When the clock signal is an analog channel (CH1-CH4), you need to set a
threshold. Press Threshold, rotate the multifunction knob or use the
pop-up numeric keypad to set the threshold.
3． Bus setting
Press Bus to enter the bus setting menu.
âš« Set the bus
Press BUS to select the digital bus for Parallel decoding, as shown in the
following table.
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
Bit0 to Bit7 are set to D7 to D0
respectively. Width is set
automatically, and you cannot
modify them.
Bit0 to Bit7 are set to D15 to D8
respectively. Width is set
automatically, and you cannot
modify them.
Bit0 to Bit15 are set to D15 to
D0 respectively. Width is set
automatically, and you cannot
modify them.
Bit0 to Bit7 are set to D0 to D7
respectively. Width is set
automatically, and you cannot
modify them.
