Chapter 11 Protocol Decoding RIGOL
MSO7000/DS7000 User Guide 11-13
⚫ EOF Error
This error is generated when the EOF condition is not met. For example, if
the Stop Bit is set to 1.5, but the actual stop bits is less than 1.5 bits, then
the red error report information (its display form is related to the value
of the horizontal time base) is displayed in the following figure.
⚫ Parity Error and EOF Error
When both the parity error and the EOF error are detected, the error report
information (its display form is related to the value of the horizontal time
base), as shown in the following figure, will be displayed.
