➢ Set the event table format: Press Format, rotate the multifunction
knob to select the display format of "Data" in the event table. Then,
press down the knob to select it. You can also press Format
continuously or enable the touch screen to select it. The available
formats include "Hex", "Dec", "Bin", and "ASCII".
➢ Set the view type: Press View, then rotate the multifunction knob
to select the form of the event table to be viewed. Press down the knob
to select it. You can also press View continuously or enable the touch
screen to select it. The available choices include "Packets", "Details",
and "Payload". You can also tap "Packets", "Details", or "Payload" at
the top of the event table to select it.
If you select "Packets", the decoded data, time, and other information
are displayed in the event table. If you select "Details", the detailed
data in the specified row will be displayed in the event table. If "…"
appears in the row of data, it indicates that the decoded data are not
fully displayed. At this time, you can view the details in the "Packets"
view. If you select "Payload", all data in the specified column will be
displayed in the event table. If "…" appears in the specified column of
data, it indicates that the decoded data are not fully displayed. At this
time, you can view the details in the "Packets" view.
➢ Export: If you select "Packets", you can export time and the
corresponding decoded data. Press Export, the save setting menu is
displayed. You can export the data table of the packets to the internal
or external USB storage device (when detected) in CSV format. For
detailed saving operation, refer to descriptions in "Store and Load".
➢ Jump to: Set the operating status of the oscilloscope to "STOP". Then,
select the data of the specified time from the event table. Press Jump
to and the specified data waveforms are displayed in the center of the
screen.
➢ Decode: The setting of this menu enables you to quickly view the
corresponding event tables of four decode modules (Decode1,
Decode2, Decode3, and Decode4). Press Decode and rotate the
multifunction knob to select a decode module, then press down
the knob to select it. You can also press Decode continuously or
enable the touch screen to select it.
5. Interpret the decoded 1553B data
⚫ C/S: command/status word. It is displayed as a blue-green patch.
⚫ RTA: remote terminal address of the command/status word. It is displayed
as a tangerine patch.
⚫ C/S data: the rest data value of the command/status word. Its display
format is the same as that of the bus data (Hex, Dec, Bin, or ASCII),
displayed as a green patch.
⚫ Parity bit: displayed as a yellow-green patch; when errors occur, displayed
as a red patch.
⚫ Data word data: data of the data word. Its display format is the same as
