RIGOL Chapter 6 Operations and Measurements
6-46 MSO8000 User Guide
âš« Press BY, then rotate the multifunction knob to adjust the vertical
position of Cursor B (Y cursor).
Enable the touch screen and tap BY, then the numeric keypad is
displayed. Set the vertical position of Cursor B (Y cursor). The vertical
axis indicates voltage, and the unit of its setting value is the same as
that of the vertical axis.
âš« Press AY BY, then rotate the multifunction knob to adjust the
vertical position of Cursor A and Cursor B (Y cursors) simultaneously.
The vertical spacing between Cursor A and Cursor B (Y cursors)
remains unchanged.
Note: If one of the three items (AX, BX, and AX BX) or one of the three items
(AY, BY, and AY BY) is selected, you can press down the multifunction
knob continuously to switch among the three items.
4. Select Screen Region
âš« When the delayed sweep function is disabled, press More, and "Main" is
automatically selected under Region and cannot be modified.
âš« When the delayed sweep function is enabled, the screen is divided into two
regions: main time base and zoomed time base. Press Region continuously
to select "Main" or "Zoom".
➢ When "Main" is selected, the cursor is displayed in the main time base
region, and you can measure the parameters in the main time base
region.
➢ When "Zoom" is selected, the cursor is displayed in the zoomed time
base region, and you can measure the parameters in the zoomed time
base region.
5. Set the Horizontal/Vertical Measurement Unit
âš« When "X" is selected under Select, you can set the horizontal measurement
unit. When the source can be Math1-Math4, this menu is grayed out and
disabled.
Press More → Hori. Unit, and rotate the multifunction knob to select
the horizontal measurement unit. Then press down the knob to select it. You
can also press Hori. Unit continuously or enable the touch screen to select
it. The available units include "s", "Hz", "Degree(°)", and "Percent(%)".
➢ s: measures the time value at X Cursor (taking the trigger position as
reference). The measurement results include AX, BX, â–³X, and 1/â–³X.
Wherein, AX, BX, and â–³X all indicate time, and 1/â–³X indicates
frequency.
➢ Hz: measures the frequency value at X Cursor (taking the trigger
position as reference). The measurement results include AX, BX, â–³X,
and 1/â–³X. Wherein, AX, BX, and â–³X all indicate frequency, and 1/â–³X
indicates time.
