RIGOL Chapter 19 Store and Load
19-10 MSO8000 User Guide
Figure 19-1 Disk Management Interface
Execute the following operations through the disk management menu:
âš« To Select a File Type
âš« To Create a Folder
âš« To Delete a File or Folder
âš« To Copy and Paste a File or Folder
âš« To Rename a File or Folder
âš« To Clear the Internal Memory Safely
To Select a File Type
Except the image storage, waveform storage, and setup storage, the oscilloscope
can also save the files of advanced applications.
Press Storage → Disk → File Type, rotate the multifunction knob to select the
desired file type. The default is "*.*". In the current path, only the file whose suffix of
its file name matches that of the file type selected will be displayed in the current
path.
To Create a Folder
Before using the external disk, make sure that a USB storage device (FAT32 format,
flash memory) is connected correctly.
In the disk management interface, rotate the multifunction knob to select the
storage location. By default, the internal memory "Local Disk(C)" is selected. Press
NewFolder to enter the interface, as shown in Figure 19-2.
