Rigol MSO8104

RIGOL Chapter 19 Store and Load
19-18 MSO8000 User Guide
Frequency
1 kHz
Amplitude
500 mV
Offset
0 V
Start Phase
0°
Setting Type
Off
Impedance
HighZ
Cursor
Mode
Off
Manual
Select
Y
Source
CH1
AY
100 mV
BY
-100 mV
Vertical Unit
Source
Hori. Unit
s
Region
Main
Track
AX Source
CH1
BX Source
CH1
AX
-1 μs
BX
1 μs
Track
X
XY
AX
-233.3 mV
BX
100 mV
AY
-233.3 mV
BY
-100 mV
Measure
Indicator
Off
Storage
Auto Name
ON
Header
ON
Save Image
Format
Invert
OFF
Color
Color
Window
Show
Save Wave
Data Source
Screen
Format
*.bin
Window
Show
