ring Stick Up Cam Wired User Manual

Feed the included USB cable through the hole in the bottom
cover and plug it into your Stick Up Cam.
Then, connect the cable to the included USB power supply,
and plug the power supply into a socket.
To power Stick Up Cam with USB:
(For indoor use only)
5

ring Stick Up Cam Wired Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Bluetooth	-
Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	1
Power source type	AC, PoE
Total megapixels	- MP
Maximum resolution	- pixels
Supported video modes	1080p
Cables included	LAN (RJ-45), Micro-USB
Minimum illumination	- lx
Audio system	2-way
Operating temperature (T-T)	-20.5 - 48.5 °C
Form factor	Box
Mounting type	Ceiling/Wall/Desk
Product color	Black
Mobile operating systems supported	Android, iOS
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	60 mm
Height	97 mm
