Rinnai 37 HW_CF OIM
TABLE 4. APPLIANCE DIMENSIONS - B SERIES & UNIVERSAL WATER CONTROLLER
All dimensions in mm
unless otherwise stated.
Model
B16
B20
B26
8QLYHUVDO
REU-A1620WB REU-A2024WB REU-A2626WB
MC-601Q
A Width 351 351 351 90
B Depth Min / Max 195 195 195 21
C Height Unit 531 531 531 120
D +HLJKWLQFOXGLQJEUDFNHWV 571 571 571 -
E
Hot water outlet
(from wall)
Min / Max 87 87 87 -
F +RWZDWHURXWOHWIURPFHQWUH 105 105 105 -
G
Cold water inlet
(from wall)
Min / Max 68 68 68 -
H &ROGZDWHULQOHWIURPFHQWUH 10 10 10 -
I
*DVFRQQHFWLRQ
(from wall)
Min / Max 77 77 77 -
J *DVFRQQHFWLRQIURPFHQWUH 83 83 83 -
K Neutraliser outlet (from wall) ----
L 1HXWUDOLVHURXWOHWIURPFHQWUH ----
M
*DVFRQQHFWLRQOHQJWKIURPEDVH 40 40 40 -
&ROGFRQQHFWLRQOHQJWKIURPEDVH 50 50 50 -
+RWFRQQHFWLRQOHQJWKIURPEDVH 39 41 41 -
Condensate outlet (from base) ----
N Flue spigot height - Internal models ----
O 9HUWLFDOPRXQWLQJKROHFHQWUHV ---84
P
&DEOHDFFHVVKROHVL]H ---Ø20
Position - - -
Centre
0HDVXUHPHQWLVIURPWKHOHIWRIWKHFHQWUHOLQH
M
B
DC
A
E
F
J
H
I
G
Universal Water Controller - MC-601Q
A
B
C
Drawings are not to scale
P
O
B Series
SPECIFICATIONS
