Rinnai MC 70 2A User Manual

- 20 -
OPERATION WITH DELUXE TEMPERATURE CONTROLLERS
Setting the Sound Volume
The sound volume for all Temperature Controllers can be set individually. Note that this can be done
with the Temperature Controllers switched off.
Press the ‘Sound Vol.’ Button located
behind the flip panel.
The volume will change as follows:
Voice Volume
Initial Setting Medium
Press Once High
Press Again Off
Press Again Low
Using Hot Water
The hot water delivery temperature can be controlled from either the Kitchen Controller
(MC-70-2A) or the Bathroom Controller (BC-70-2A).
Deluxe Kitchen Controller
Ensure the system is switched on. When the system is
ON, the monitors will be lit. Confirm that the ‘Transfer’
button is lit. If not, press the ‘Transfer’ button once.
Select the desired temperature using the ‘Hot water temp.’
buttons. The selected temperature will be displayed on
both the Kitchen and Bathroom Controllers at the top of
each monitor.
Open the hot water tap. The hot water unit will activate
and the red combustion symbol will light on both the
kitchen and bathroom monitors.
CHECK WATER TEMPERATURE BEFORE USE.
A parent should always check the temperature before a child is
p
laced in contact with hot water.
Clock Hour Min.
Vol .
C
AM
Hot wa te r
tem p.
00 00
ON/OFF
MC -70-1A
Transfer
Sound
Cooler
Hott er
Clock Hour
Min.
Vol.
C
AM
Hot water
temp.
00 00
ON/OFF
MC -70 -1A
Trans fer
Sound
Cooler Hotter
C
AM
Transfer
HOT
COLD
Consumer safeguards: With the hot water tap open and a temperature of
43°C or higher selected, if the temperature is decreased to below 43ºC, and
then raised again the maximum available temperature will be 43°C, in
addition temperature ‘priority’ cannot be transferred between controllers.
CAUTION
NOTE
C
AM
- 16 -

Rinnai MC 70 2A Specifications

General

Brand	Rinnai
Model	MC 70 2A
Category	Temperature Controller
Language	English
