BEFORE YOU START
INSTALLATION REQUIREMENTS
This heater must be installed by an authorised person. The installation must conform to local regulations. The
installation must also comply with the instructions supplied by Rinnai.
Service and removal must be carried out by an authorised person.
CERTIFICATION
The Rinnai Energysaver® Range has been certified by the Australian Gas Association.
The AGA Certification Number is shown on the appliance dataplate.
No parts or functions should be modified or permanently removed from the heater.
Please keep these instructions in a safe place for future reference.
FLUE INSTALLATION MANUAL
These instructions are to be used in conjunction with the Rinnai “Energysaver Space Heater Co-Axial Flue System
Installation Manual” These components Installation Manual” supplied with flue kits ESDFK or ESKIT03.
UNPACKING THE APPLIANCE
Check for damage and missing parts. If the heater is damaged or missing any parts, contact your supplier for
advice.
Before installing the appliance, check it is labelled for the correct gas type (see label on the rear of heater).
Refer to local gas authority for confirmation of gas type if you are in doubt.
CARTON CONTENTS / ITEM CHECKLIST
Ensure that the components listed are present before proceeding with the installation.
* For direct flue kit `ESDFK´ installations ONLY refer to page 22 for installation details.
Check you have the following:
1 x One of the following Rinnai Space Heaters
RHFE-559FDT
RHFE-1005FDT
2 x Keys for lockable control panel door.
1 x Rear Cover set, comprising of left, right and top cover panels
1 x Bolt pack containing;
Part RHFE-559FDT RHFE-1005FDT
Plastic inlet hose clamps 2 0
Air intake baffle ring* 1 0
Flue adapter 0 1
Stainless steal sheath clamp Large 0 1
Stainless steal sheath clamp 1 0
Securing brackets 2 2
8g x 32mm screws 2 2
150mm long cable tie 1 1
Flue lock clamp L 0 1
Flue lock clamp S 1 1
6g x 10mm button head screws 2 0
6g x 8mm pan head screws 4 7
