ABOUT YOUR ENERGY SAVER SPACE HEATER
CONTROL PANEL GENERAL LAYOUT
8
9
2
1
4
3
6
10
Shows temperature (Set / Room),
or coded error message.
TEMPERATURE DISPLAY
2
Indicated that the Temperature
Display is displaying the Set
temperature.
SET TEMPERATURE
INDICATOR
3
Indicated that the Temperature
Display is displaying the Room
temperature.
ROOM TEMPERATURE
INDICATOR
4
Main switch for turning 'ON / OFF'.
'ON' / 'OFF' BUTTON
1
Indicates that the Child / Function
Lock is actived (see page 11).
CHILD / FUNCTION
LOCK INDICATOR
7
Indicates that the filter needs
cleaning
(see page 13).
FILTER INDICATOR
8
Indicates that the appliance
is turned ON and whether
the burner is alight.
POWER ON/
COMBUSTION INDICATOR
9
Indicates that the Economy mode is
in operation (see page 11).
ECONOMY INDICATOR
5
Selects energy saving function.
ECONOMY BUTTON
6
Increases or decreases the
temperature setting. Also used
to set Child /Functiom Lock.
TEMPERATURE
ADJUSTMENT BUTTONS
10
1
624 7
10
5
RHFE-559FDT
RHFE-1005FDT
3 5
7
Both Models
