13 Rinnai CVent
Sample Roof Assembly
CVent 8-in Roof Termination
Kit with PVC Adapter
#7900057 / 791007PPS
Cvent pitched roof moldable
flashing #790003
Field Supplied
PVC Components
Field Supplied
8” PVC Flashing
CVent 8in Vent Rain Cap
(Exhaust) #790034
OPTIONAL
Vent termination per ANSI Z223.1/NFPA
54. For clearances not specified in ANSI
Z223.1/NFPA 54, clearances are in
accordance with local installation codes
and the requirements of the gas supplier.
Intake
Exhaust
