Prepare for installaon
Parts included
Tools needed
Materials needed
• Tankless water heater
• Pipe wrenches (2)
• Adjustable pliers
• Screwdrivers (2)
• Wire cuers
• Gloves
• Safety glasses
• Level
Tools that might be needed
• Hammer drill with
concrete bits
• Saw
• Threading machine with
heads and oiler
• Core drill with diamond
head
• Torch set
• Copper tubing cuer
• Steel pipe cuer
Materials that may be needed
• Soap soluon
• Pressure relief valve
• Teon tape
(recommended) or pipe
compound
• Heat tape
• Pipe insulaon
• Electrical wire and
conduit per local code
• Concrete wall anchors
• Oponal pipe cover
• Oponal temperature
controller
• 5/8” ID PVC exible
tubing
• 2 conductor 22 AWG
wire for controller
• Single gang electrical
box
• Wire nuts
• Unions, drain valves,
isolaon valves
Consideraon of care for your water heater should
include evaluaon of water quality.
The water must be potable, free of corrosive
chemicals, sand, dirt, or other contaminates. It is up
to the installer to ensure the water does not contain
corrosive chemicals, or elements that can aect or
damage the heat exchanger. Water that contains
chemicals exceeding the levels below aect and
damage the heat exchanger. Replacement of the
heat exchanger due to water quality damage is not
covered by the warranty.
Determine Installaon Locaon
Water Quality
* Source: Part 143 Naonal Secondary Drinking Water
Regulaons
You must ensure that clearances will be met.
Consider the installaon environment, water quality,
and need for freeze protecon. Requirements for the
gas line, water lines, electrical connecon, and
• Should overheang occur or the gas supply fail to
shut o, turn o the manual gas control valve to
the appliance.
(En cas de surchaue ou si l’alimentaon en gaz ne
s’arrête pas, fermez manuellement le robinet
d’arrêt de l’admission de gaz).
• Keep the air intake locaon free of chemicals such
as chlorine or bleach that produce fumes. These
fumes can damage components and reduce the
life of your appliance.
Maximum Level
Total Hardness Up to 200 mg / L
Aluminum * Up to 0.2 mg / L
Chlorides * Up to 250 mg / L
Copper * Up to 1.0 mg / L
Dissolved Carbon Dioxide (CO2) Up to 15.0 mg / L or PPM
Iron * Up to 0.3 mg / L
Manganese * Up to 0.05 mg / L
pH * 6.5 to 8.5
TDS (Total Dissolved Solids) * Up to 500 mg / L
Zinc * Up to 5 mg / L
If you install this water heater in an area that is
known to have hard water or that causes scale build-
up the water must be treated and/or the heat
exchanger ushed regularly.
When scale build-up in the heat exchanger begins to
aect the performance of the water heater, a
diagnosc code “LC#” will display. Flush the heat
exchanger to prevent damage to it. Scale build up is
caused by hard water set at a high temperature.
Rinnai oers Southeastern Filtraon’s “ScaleCuer
Water Condioning System” that oers superior lime
scale prevenon and corrosion control by feeding a
blend of control compounds into the cold water
supply.
Part Number Descripon
103000038
Southeastern Filtratrion
ScaleCuer System 3/4” Feed
103000039 ScaleCuer Rell
condensate disposal can be found in their respecve
installaon secons of this manual.
