ARBOTOM
®
- Manual 39
3D Tomography
For 3D applications the height of sensor positions must be specified individually. The sensors must
furthermore be ordered in levels. A level is defined as a complete circulation of the sensor chain. The
next and the following circulations are assigned to further levels.
Sensors can also be ordered in distinct levels or like a screw around the tree. If using the screw like
setting you should not be using the algorithm “interpolate levels”
Level 0
Level 1
1st sensor of level 0
1st sensor of level 1
last sensor of level 1
Last sensor of level 0 1st sensor of level 0
last sensor of level 1 1st sensor of level 0
