9
- Make sure the back and bottom panels are properly aligned and
tighten the two structure screws (1 and 2) on each side of the
L-Shape Structure.
Chapter 1 11
BACK / BOTTOM PANEL ASSEMBLYMORPHEUS
Create an L-Shape structure
- Lift the back panel to an upright position, in order to make an
L-Shaped structure, , tke out the shipping foam, mini tower
expansion bracket and 80.0 mm fan and set them aside for later use.
1
2
To Next Page
