Chapter 2 18
9
Secure the structure
- Align the holes for the preassembled middle panel and base plate,
join both parts by placing and tightening two (1 & 2) structure screws.
MIDDLE PANEL ASSEMBLYMORPHEUS
1 2
screw them from the outside in
