Create an L-Shape structure
9
Note: be careful as the front panel is not secured.
- Lift the front panel to an upright position, in order to make an
L-Shaped structure, take out the cooling bracket and the two 120.0 mm
red LED fans and set them aside for later use.
1
2
- Make sure the front and top panels are properly aligned and
tighten the two structure screws (1 and 2) on each side of the
L-Shape Structure.
Chapter 3 27
TOP / FRONT PANEL ASSEMBLYMORPHEUS
