Riotoro MORPHEUS - Secure the Trim to the Structure

tighten trim screws from the outside
tighten structure screws from the inside
Secure the trim to the structure
- Start by positioning the bottom trim, place and tighten two (1 and 2) trim
screws, place the top trim, place and tighten three (3, 4 and 5) trim screws
and finally place and tighten four (6, 7, 8 and 9) structure screws.
