Rish DELTA VAF NX User Manual

When the least significant digit has been set pressing
the “ ” key will advance to the Potential Transformer
Primary Value confirmation stage.
Screen showing display of 0.120 kV i.e. 120 Volts
indicating steady decimal point and cursor flashing
at the “hundreds of volts” position.
Pressing the “ ” key sets the displayed value and
will advance to the “Potential Transformer Secondary
Value” screen (See Section 3.2.1.3).
3.2.1.3 Potential Transformer
Secondary Value
The value must be set to the nominal full scale
secondary voltage which will be obtained from
the Transformer when the potential transformer
(PT) primary is supplied with the voltage defined
in 3.2.1.2 potential transformer primary voltage.
Pressing the “ ” key accepts the present value at the
cursor position and advances the cursor to the next .
The ratio of full scale primary to full scale secondary
is defined as the transformer ratio.
The PT Secondary value can be set from 100VL-L
to 500VL-L.
12
If the scaling is not correct, pressing the “ ” key
will return to the “Potential Transformer Primary digits
flashing indicating Value Edit” stage with that multiplier
(decimal point position) should be selected.
.
less significant digit
L3 L1 Hz P F
If the scalling is not correct, pressing the “ ” key
will return to the “Potential Transformer Secondary
Value Edit screen.
A
M K W h
V
A
K
r h
K
V
M
L1
L2
DM
L3
A h
L3 L1 Hz P F
SY
.
.
Pressing the “ ” key sets the displayed value and “ ”
key will advance to the "Current Transformer Primary
Value" screen (See Section 3.2.1.4).
3.2.1.4 Current Transformer Primary Value
The nominal Full Scale Current that will be displayed
as the Line currents. This screen enables the user to
display the Line currents inclusive of any transformer
ratios, the values displayed represent the Current in
Amps.
Pressing the “ ” key will
enter the Current Transformer
Primary Value edit mode.
This will scroll the value of the
most significant digit from 0
through to 9
Pressing the “ ” key will advance to the next less
significant digit. (* Denotes that decimal point will
be flashing).
Pressing the “ ” key
advances to the Current
Transformer Primary Value”
screen (See Section 3.2.1.4).
Transformer Secondary Value edit mode.
Pressing the “ ” key
will enter the Potential
Pressing the “ ” key advances to the Current
Transformer Secondary Value” screen (See Section
3.2.1.5).
The minimum value allowed is 1, the value will be
forced to 1 if the display contains zero when the “ ”
key is pressed.
If the scaling is not correct, Pressing the “ ” key will
return to the Current Transformer Primary Value edit
stage with the most significant digit highlighted
(associated decimal point flashing) and the bottom
line of the display will be blanked.
The CT Primary value can be set from 1A
to 9999A.
