Rish DELTA VAF NX User Manual

13
V
A
K
r h
K
V
M
L1
L2
DM
A h
SY
3.2.1.5 Current Transformer Secondary Value
This screen is used to set the
value for Current Transformer
Secondary value, “5” for 5A
or “1” for 1A can be selected.
Pressing “ ” key advances
to the Demand Integration
Time (See Section 3.2.1.6).
Pressing the “ ” key will enter the CT Secondary
value edit mode and pressing the “ ” key scroll
the value through the values available.
Pressing “ ” key sets the displayed value and “ key”
will advance to “Noise Cutoff” screen (See
Section 3.2.1.6).
A
M K W h
V
A
K
r h
V
M
L1
L2
DM
L3
A h
SY
V
M K W h
L2 M L3 W Ø
3.2.1.7 Auto Scrolling
V
P
A
M K W h
L1
L3 L1 Hz P F
SY
This screen allows user to
enable screen scrolling.
Pressing ” ” key advance
to the No. of Poles Selection
screen (See Section 3.2.1.8).
V
A
r h
K
V
M
L1
L2
DM
L3
A h
SY
Pressing the “ ” key will
enter the Auto Scrolling
Screen edit mode and
toggle the status ‘Yes’ and
‘No’.
Pressing the “ ” key will
select the status displayed
and “ ” key advance to the
No. of Poles Selection screen
(Section 3.2.1.9).
This screen enables to set No. of poles of a Generator
of which RPM is to be measured and to which the
instrument is connected to monitor its parameters.
3.2.1.8 No. of Poles Selection
Pressing “ ” key returns to
System Type Selection
screen (See section 3.2.1.1).
Pressing the “ ” key will
enter the No. of Poles
selection edit mode.
Pressing “ ” key scroll the number from
02 to 40 in step of 2. After 40 it scrolls the
number again to 02.
Pressing “ ” key set the number on screen as
number of poles of generator & “ ”key
advance to System exit selection menu.
This screen allows the
user to set Low noise
current cutoff in mA.
Pressing " " key
advances to the Auto
scrolling.
3.2.1.6 Noise cutoff
Pressing " " will enter into the Noise Cutoff
selection edit mode.
r h
DM
SY
