Rish DELTA VAF NX User Manual

42
Isolation
High Voltage Test
Environmental conditions
Operating temperature
0
0 to +60 C
Storage temperature
0
-25 to +70 C
(as per IEC 60688)
Relative humidity
0-95% RH (Non
condensing)
Warm up time
3 minute (minimum)
Shock
30gn (300 m/s^2), duration 18ms
Vibration
10 .. 150 ..10 Hz,
0.15mm amplitude
Enclosure
Enclosure front
IP 54
Enclosure back
IP 20
Dimensions
Bezel Size
96mm x 96mm DIN
43718
Panel cut out
+0.8 +0.8
92 mm X 92 mm
Overall Depth
55 mm
Panel thickness
1 - 3mm for self clicking,
1 - 6mm for swivel
screws
Weight
250 grams Approx.
Relay output Option
Relay
Switching Voltage
1CO
250VAC, 5Amp ;
& Current
30VDC, 5Amp
ModBus ( RS 485 ) Option :
Protocol
ModBus ( RS 485 )
Baud Rate
4.8k 9.6k, 19.2k,
38.4k, 57.6k
(Programmable)
Parity
Odd or Even, with
1 stop bit,
or None with 1 or 2 stop bits
All Circuit vs Surface
3.5 kV RMS, 50Hz, 1min
Input/AUX vs Others
Relay/RS485 vs Others
Input voltage vs Input Current
3.5 kV RMS, 50Hz, 1min
3.3 kV RMS, 50Hz, 1min
2.2 kV RMS, 50Hz, 1 min
Input vs AUX
3.3 kV RMS, 50Hz, 1 min
IP for Water and Dust
Pollution Degree
Installation Category
IEC 60529
2
lll
CISPR 11
Emission
Rs485 vs Relay
2.2 kV RMS, 50Hz, 1 min
