RPR-4000 Standard Pulser Configurations
RPR-4000-VHP RPR-4000-HP RPR-4000 RPR-4000-HD
Pulser Configuration:
Very High
Power
High Power Standard
High Duty
Cycle
Option 1 Option 2
Maximum Output Power[1] 20 kW 15 kW 15 kW 8 kW 400 W
Equivalent Output Voltage into
50 Ω 2850 Vpp 2450 Vpp 2450 Vpp 1800 Vpp 400 Vpp
Maximum Duty Cycle 0.6% 0.3% 0.3% 1.0% 10%
Maximum Pulse Width 100 μs 200 μs 100 μs 200 μs 5 ms
Optimum Frequency Range
(Standard)
50 kHz –
0.5 MHz
50 kHz –
0.5 MHz
250 kHz –
2.5 MHz
250 kHz –
5 MHz
100 kHz –
10 MHz
Optional Frequency Range[2] 0.25 MHz –
1 MHz
50 kHz –
1 MHz
50 kHz –
2 MHz
Bandwidth @ Maximum
Output ~1 decade ~1 decade ~1 decade ~1 decade
~2 decades
Internal Diplexer[3] No No No Yes
Yes
[1] Output power specified is the Peak Envelope Power ( PEP = (Vrms)
2
/ R
load
) when operating with a low VSR 50 Ω load.
[2] Custom frequency ranges are available – please contact RITEC for details.
[3] Used for pulse-echo operation. For systems without internal diplexers, an external diplexer accessory suitable for your
application may be available – please contact RITEC for details.
