RPR-4000
Operations manual
REV 8-21 38
Receiver commands
Parameter Command Data range Units Query Echo
Input
select
IN:x<CR> 1,2, A IN:?<CR> IN:x<CR>
Receiver
gain
GA:xx.x<CR> 20.0 to 99.9 dB GA:?<CR> GA:xx.x<CR>
High pass
filter
HF:n<CR> 1,2,3,4,5,6,
7, or 8
HF:?<CR> HF:<hpf-id><CR>
Low pass
filter
LF:n<CR> 1,2,3,4,5,6,
7, or 8
LF:?<CR> LF:<lpf-id><CR>
Trigger and repetition rate commands
Parameter Command Data range Units Query Echo
Trigger
source
TG:x<CR> I,E, or C TG:?<CR> { INT | EXT|XPC}<CR>
INT for internal
EXT for external
XPC for remote
Repetition
rate
RR:xxxxx.xxx<CR> See Table
3.2
HZ RR:?<CR> RR:xxxxx.xxx<CR>
Trigger
remotely
CT:<CR> CT:<CR>
Table 3.2 Allowable repetition rate settings
10000.000 01000.000 00100.000 00010.000 00001.000 00000.100
08000.000 00800.000 00080.000 00008.000 00000.800 00000.080
05000.000 00500.000 00050.000 00005.000 00000.500
04000.000 00400.000 00040.000 00004.000 00000.400
02500.000 00250.000 00025.000 00002.500 00000.250
02000.000 00200.000 00020.000 00002.000 00000.200
01600.000 00160.000 00016.000 00001.600 00000.160
01200.000 00125.000 00012.000 00001.250 00000.125
