Rittal LCP Rack DX 12 - Page 63

Rittal Liquid Cooling Package 63
16 Further technical information
16
Exterior temperature 45°C
At very high exterior temperatures above +45°C, the de-
vice will achieve a maximum cooling output of approx.
10 kW.
Fig. 69: Diagrammatic view
Exterior temperature -20°C
The device has also been tested at very low exterior
temperatures of -20°C and very low cooling outputs of
2kW and 4kW.
Exterior tempera-
ture [°C]
45
Cooling output [kW] 3 6 9 9.76
Inlet temperature
[°C]
25.63 26.55 28.39 30.35
Outlet temperature
[°C]
22.08 19.87 20.23 22.04
dT [°C] 3.55 6.68 8.16 8.31
Output [kW] 1.084 2.258 4.182 4.676
Tab. 39: Tabular view
Exterior tempera-
ture [°C]
-20
Cooling output [kW] 2 4
Inlet temperature
[°C]
26.08
Outlet temperature
[°C]
22.99
dT [°C] 3.09
Output [kW] 2.02 6.07
Tab. 40: Tabular view
0
10
20
30
40
024681012
